433MHZ DC 12V 10A 10 channel RF Wireless Remote Control system Individual learning code light/lamp/led band

$15.77 USD

~~$15.77 USD~~ $15.77 USD

Sale Sold out

Quantity

The newly developed independent 12 volt 10-way remote control switch with 10 10A relays, each relay has a learning button with the remote control, with 10 single-button remote control or with a 10-key remote control. Each independent work, without disturbing each other, another way to switch work and three work toggle indicator. Red (jog), yellow (self-locking), green (interlock).

Mainly used in lighting, LED control, electric doors, windows, lifting equipment, gates, elevators, industrial control and security industries and other fields.

Second, the parameters

Working voltage: DC12V (can be customized 24V / 36V)

Working frequency: 315MHz / 433MHz (optional)

Standby current: 12mA

Receiving sensitivity: - 110 DBM

Work: Jog, self-locking, interlocking (work mode switch button to adjust)

Size: 135 * 73 * 18mm

Third, the working methods

Jog - Press the button to switch the way to the red light

Self-locking - Press the button to switch to work yellow to light

Interlock - Press the button to switch to work, the green light

Fourth, clear the stored information

Long press the learning button for about 6 seconds until the working mode indicator light, indicating that the stored information has been successfully cleared.

Fifth, learning methods and steps

Click the learning button, the indicator light off, let go, press any key on the remote control flash three times after the light, said the success of learning.

Note: 315mhz and 433 mhz are available ,433mhz will be sent out if there is no demand on frequency

3.Package Included:

1 x Receiver

1 x Transmitters

1 x Receiver

1 x Transmitters
